STR-環保風力循環回收式噴砂房效果圖

STR-Environmental protection wind cycle recovery sandblast room designsketch

◆噴砂（丸）房的結構平臺

Composition of the sandblasting (shot) room system

1、崗位室  Studio

2、噴砂系統的  Sandblasting  system

3、金剛石工具回收并設備  Abrasive recycle system

4、抑塵系統  Dust removal system

5、工件產品輸送帶軟件  Workpiece conveying system

6、有效控制整體  Control system

7、采光設備  Lighting system

 ◆適用人群範圍 Applicable scope

超大鑄件鍛件、對接焊鋼構造、箱式變壓器副油箱、建筑項目機制、重型機車來往車輛、工業鍋爐營造、石油化工機制、漁業修造等噴砂除銹方法。

Large castings and forgings welding steel structure, transformer oil tank, engineering machinery, locomotives, boiler manufacturing, chemical machinery, ship building blast cleaned, etc.

 ◆好產品基本特征 Product features

噴砂房是我公司在蜂窩地板技術的基礎上，自行開發、設計的環保型蜂窩式噴砂（丸）房，可按客戶的產品特性、噴砂要求等設計制作。蜂窩地板噴砂房是利用風機的風力為動力，將磨料通過回料管道吸送到旋風分離器中進行分離，最后進入噴砂系統循環利用。

Sandblasting room  is our company in introducing foreign advanced cell technology based on the floor, , the development, the design of the environmental protection cellular gush arenaceous (shot) room by ourselves, according to customers' product characteristics, sandblasting design requirements, etc. Cellular floor gush arenaceous room is the wind power by fan for abrasive materials, will back through the pipe to cyclone separator suction of separation and finally into gush arenaceous system recycling.

體現了如下優缺：

1、省去了常規噴砂房砂料輸送煤循環系統的螺旋輸送機，斗式提升機以及地下工程，不需建造地坑，節約了地基施工費用，大大節約了工程成本；

2、研磨材料回收公司率高，方便于清換研磨材料；

3、基本電氣公司元器件封裝均按照國外產品的，具有著安全不靠譜性能安全不靠譜穩定，安全不靠譜不靠譜，利用生命周期長，養護簡潔明了；

4、噴砂房室體內有高清晰的能見度，室體自然補風，節約能源消耗；

5、該設備運用雙極清灰，首級運用漩風脫離器，二是級用濾網式清灰系統軟件，其總清灰學習效率led光通量99.99%這；

6、在噴砂房正面房頂上部，配有“聲光報警系統”，在噴砂房內，配有急停呼叫按鈕；

7、各設計電子操作平臺所采用互鎖操作，當之中一設計造成設備故障時，相關設計均立即暫停本職工作，噴槍立即暫停噴射式；

8、房體選擇房建結構設計結構設計，金屬機身言簡意賅、好看、規定，消除噪音成效好，且裝設簡單。

Advantages

1. Omitted conventional Sandblasting room sand conveying coal circulation system, screw conveyor a pattern lift machine and underground project, no need to build the pit and save foundation pit construction cost, greatly reduce the project cost;

2. high  abrasive recycle efficiency, easy to change abrasive;

3. The main electrical components are imported products, have the stable performance, safety and reliability, long life, easy maintenance;

4. Sandblasting room inside has high-resolution visibility, Chambers fill the wind, save energy natural consumption;

5. This machine use double levels of dust removing, the first level is the cyclone separator, the second type is filter dust removal system. Its total removal efficiency may reach above 99.99%;

6. In sandblasting room roof, equipped with a "positive upper sound-light alarm system", in the room, sandblasting with abrupt stop call button;

7. The electric control system uses interlock control, while one system malfunction, related system are to stop working, stop spraying gun;

8. Building decoration design room body appearance, simple , beautiful, standard, good noise reduction result  and convenient installation.
